The BVS (Ball Valve Servo) is a motor to retrofit existing and installed ball valves into smart water controlling devices.
- The motor is powered by a 12 V external power supply or optional a battery block.
- Simple
- Tools-Free: Just snap on and turn 2 knobs. Done in less then one minute!
- Elbow proof: Can be installed on pipe elbows by adjustable clamps position
- Smart Adaptive Torque Control: Protects motor, valve and pipe for long term operation
- Outdoor Proof: IP67 rated, worked even submerged under water
- Integrated Water Detection Probe and Freeze Detection.
- Works Offline as well.
| Application | |
|---|---|
| Application | Water valve |
| Benefits | |
| In/Outdoor usage | Indoor & Outdoor |
| Features | |
| Actuator functionality | Water-valve shut off, Retrofit solutions |
| User interaction | Unknown |
| Accessories | water leak detection probe, freeze detection |
| Connectivity data | |
| Protocols / Connectivity | LoRaWAN |
| Power supply | |
| Powered by | External power source, 12 V, Battery pack (optional) |
| Mechanical data | |
| Width (mm) | 65 |
| Depth (mm) | 147,6 |
| Height (mm) | 100 |
| Internal | |
| Yggio decoder | Unkown |
| Fortnox Article number | SEN-30_135 |
| Vendor article number | BVSLWE01 |
| URL | https://www.aqua-scope.com/ball-valve-servo.html |
| Manufacturer | Aqua-Scope |
