ELT-2-HP is a general LoRaWAN ™ device that measures analogue or digital signals.
ELT-2-HP has a multifunction input like ELT-1, but also an additional I / O. ELT-2-HP can, for example, used with electric meters, flow meters, analog sensors, humidity sensors or temperature sensors.
The ELT-2-HP is closed in an IP67 box and is designed to be outside. Inside the ELT-2-HP you will find four internal sensors: a temperature sensor, a humidity sensor, an accelerometer and an atmospheric pressure sensor.
The battery life is estimated to be up to 10 years, but depends on sample interval, transmission range, data rate and environmen
| Benefits | |
|---|---|
| In/Outdoor usage | Indoor & Outdoor |
| Features | |
| Sensor | Temperature, Humidity, Accelerometer, Air pressure |
| Functionality | Measure analogue or digital signal, Multi-functional input |
| User interaction | Unknown |
| Connectivity data | |
| Protocols / Connectivity | LoRaWAN |
| Power supply | |
| Powered by | Battery, 1 x 3,6V ER14505 |
| Mechanical data | |
| Width (mm) | 94 |
| Depth (mm) | 35 |
| Height (mm) | 59 |
| Internal | |
| Yggio decoder | elsys-elt-2 |
| Fortnox Article number | SEN-30_098 |
| Vendor article number | 365 |
| URL | https://www.elsys.se/en/lora-elt-2 |
| Manufacturer | Elsys |
